Fanvil X3SP User Manual

<文档标题>
Figure 33 - Default Line ...................................................................................................... 28
Figure 34 - Dialing a Number before Audio Channel Opened ........................................... 29
Figure 35 - Dial a Number after Audio Channel Opened ................................................... 30
Figure 36 - Calling Remote Party ....................................................................................... 31
Figure 37 - Incoming Call Screen ....................................................................................... 31
Figure 38 - Talking Mode Screen ....................................................................................... 32
Figure 39 - Call Holding Screen .......................................................................................... 33
Figure 40 - Dual Calls ......................................................................................................... 34
Figure 41 - Conference Call ................................................................................................ 35
Figure 42 - Phonebook Screen ........................................................................................... 36
Figure 43 - Phonebook is Empty ........................................................................................ 37
Figure 44 - Browsing Phonebook ....................................................................................... 37
Figure 45 - Add New Contact ............................................................................................. 38
Figure 46 - Group List ......................................................................................................... 39
Figure 47 - Browsing Contacts in a Group ......................................................................... 39
Figure 48 - Select (Add/Remove) Contacts in a Group ...................................................... 40
Figure 49 - Cloud Phonebook List ...................................................................................... 41
Figure 50 - Downloading Cloud Phonebook ....................................................................... 41
Figure 51 - Browsing Contacts in Cloud Phonebook.......................................................... 42
Figure 52 - Call Logs ........................................................................................................... 43
Figure 53 - Filter Call Log Type .......................................................................................... 43
Figure 54 - New Voice Message Notification...................................................................... 44
Figure 55 - Voice Message Screen .................................................................................... 45
Figure 56 - Configure the Voice Message Number ............................................................ 45
Figure 57 - DND Enabled on All Lines ................................................................................ 46
Figure 58 - Configure DND on Line .................................................................................... 46
Figure 60 - Configure Auto-answering on Line1 ................................................................. 47
Figure 61 - Auto-answering Enabled on Line1 ................................................................... 48
Figure 62 - Select Line for Call Forward Configuration ...................................................... 49
Figure 63 - Select Call Forward Type ................................................................................. 49
Figure 64 - Activate Call Forward and configure Call Forward Number ............................ 50
Figure 65 - Set Delay Time for Call Forward on No Answer .............................................. 50
Figure 68 - Web Call Controls ............................................................................................ 54
Figure 69 - Web Call, Entering Number and Select Line ................................................... 55
Figure 70 - Global Substitution Configuration .................................................................... 64

Fanvil X3SP Specifications

General

Power over Ethernet (PoE)	Yes
Power consumption (typical)	1.2 W
Wi-Fi	No
Security algorithms	AES, MD5
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, PPPoE, L2TP, OpenVPN, SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, PPPoE, 802.1x, L2TP, SNTP, FTP/TFTP, HTTP/HTTPS, TR069
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
RJ-9 ports quantity	2
Lines quantity	2 lines
Call log entries	300
Phonebook capacity	500 entries
Number of VoIP accounts	-
Certification	CE, FCC 15 B, EN55022 B, EN61000-3-2, EN61000-3-3, EN55024, EN60950-1
Voice codecs	G.711a, G.711u, G.722, G.723.1, G.726
Frequency range	0 - 7 Hz
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 65 %
Volume control	Digital
Keypad number of keys	32
Number of function keys	5

Weight and Dimensions

Depth	174 mm
Width	159 mm
Height	171 mm
Package depth	62 mm
Package width	275 mm
Package height	215 mm
