Fanvil X3SP Specifications

General

Power over Ethernet (PoE)	Yes
Power consumption (typical)	1.2 W
Wi-Fi	No
Security algorithms	AES, MD5
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, PPPoE, L2TP, OpenVPN, SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, PPPoE, 802.1x, L2TP, SNTP, FTP/TFTP, HTTP/HTTPS, TR069
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
RJ-9 ports quantity	2
Lines quantity	2 lines
Call log entries	300
Phonebook capacity	500 entries
Number of VoIP accounts	-
Certification	CE, FCC 15 B, EN55022 B, EN61000-3-2, EN61000-3-3, EN55024, EN60950-1
Voice codecs	G.711a, G.711u, G.722, G.723.1, G.726
Frequency range	0 - 7 Hz
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 65 %
Volume control	Digital
Keypad number of keys	32
Number of function keys	5

Weight and Dimensions

Depth	174 mm
Width	159 mm
Height	171 mm
Package depth	62 mm
Package width	275 mm
Package height	215 mm
