86
(MT11 - Gb2012)
ONE-WAY VIDEOINTERCOM SYSTEM
Si 411R/1
1+1
INTERCOMS *
4+1
VIDEOINTERCOMS
EXTERNAL DOOR STATIONS
AGORA' series PROFILO series MATRIX series MODY series
1 AG100V 1 PL71 1 MA71 1 MD72
1 AG21 1 PL81 1 MAS61 (
1
)1MD82
1 AG20 1 PL91 * 1 MA91 * 1 MD92 *
1 AG40CED 1 PL41PCED 1 MAS43CED 1 MD11ED
PL41PED MAS43ED 1 MD41D
INTERNAL STATIONS
ECHOS series EXHITO series COMPACT series
1 EH9161CT 1 EX3100C 1 KM8111CW
EH9161CW EX3160C KM8111W
1 9083 EX3160 1 WB8111
1 WA9100T-W 1 WB3161
1 TA9160 1 TA3160
VARIOUS ARTICLES
1 1181E Timed power-supply
1 PA ** Door release push-button (optional)
1 SE ** Electric door lock (12VAC-1A)
(
1
) Or MA61.
* Rain shelters are used instead of back boxes and hood covers.
** Articles not supplied by ACI Farfisa.
Working instructions. See page 52.
Notes
- For audio compatibility we do not suggest to connect door stations MODY series with internal devices ECHOS series.
- For wires dimensioning refer to the installation instructions and table on pages 50.
PA
SE
230V
127V
0
1181E
A
H
F
C
4
1
A
S
X
Y
H
F
10
4
X
Y
H
F
P
C
E
Mody
Matrix
Agorà
Profilo
Compact
Echos
ExhitoExhito
Agorà door station
Note. Door station AG100V do not have the terminal "E" because the requested connection is automatically done inserting the pre-assembled
cable which comes with the product (see drawing 5a on page 18).
