© 2010 HID Global Corporation All rights reserved
DTC1000/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.2)
55
Using the Advanced Settings tab
Setting Option
Resin Heat Adjust
Use this adjustment for Black resin text and barcodes if
they appear faded or too light/dark.
• Maximum Adjustment Range is +/- 100.
(Note: This control can be helpful for fine-tuning the
transfer of resin text and bar codes.)
Head Resistance
This is factory set. If the main board or the Printhead is
replaced then adjust this number.
Locate the Printhead Setting Number on the bottom of the
Printhead.
The number reads R=XXXX.
Head Home Offset
This is a calibration driven value and should not be
adjusted. If the Printhead assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed
unless directed by a technician.)
Head Contact Offset
This is a calibration driven value and should not be
adjusted. If the Printhead assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed
unless directed by a technician.)
