14.2.2 Push-button panel of the radio remote control “RCH”
14.2.3 Push-button panel of the radio remote control “SCANRECO”
14.2.4 Icon legend
14.3 Emergency station from the column (if accessible) or
Control station (version with load limiting device) (not available)
14.4 Manoeuvres to unfold the crane into a working condition
14.5 Manoeuvres to fold the crane into the rest condition
14.6 Manoeuvres to unfold the crane “C” into a working condition (only for the crane version C)
14.7 Manoeuvres to fold the crane “C” into the rest condition (only for the crane version C)
14.8 Indicator of inner boom horizontal position (on request)
15 MANOEUVRES OF THE CRANE LOADS (version with load limiting device) (not available)
16 MANOEUVRES OF THE CRANE LOADS (version with lifting moment limiting device)
16.1 Generality
16.2 Lifting moment limiting device “EVOLUTION” (LMEV) and automatic dynamic control (ADC)
16.3 Control panels of the lifting moment limiting device (if fitted)
16.4 Load handling
16.4.1 “Block due to overload condition”
16.4.2 “Winch off” (when fitted)
16.4.3 “Lifting block” (Prolink)
16.4.4 Other functional characteristics
16.4.5 Visual indicator yellow/red light
16.5 Lifting moment limiting device for two working sectors
16.6 Rotation limiting device
16.7 Setting menu
16.8 Diagnostic: alarms and warnings
16.8.1 Emergency control station on the column and exclusion tap lever
16.8.2 Exclusion tap lever 7°/8° extension (if fitted)
16.9 XP device
16.9.1 Activation and instructions for use of the XP/CR device
16.10 "JDP" Function (if fitted)
17 USE OF IMPLEMENTS
17.1 Generality
17.2 Hydraulic connections for implements - supplementary hoses
17.3 Oil cooler (heat exchanger)
18 MANUAL EXTENSIONS
18.1 Generality
18.2 Lifting moment limiting device “ELECTRONIC” for the manual extensions
19 CONTROLS TO OPERATE THE HYDRAULIC IMPLEMENTS OF THE CRANE
20 HYDRAULIC JIBS
20.1 Generality
20.2 Identification of the hydraulic jib
20.3 Nomenclature of the hydraulic jib
20.4 Ma no e u vres to un fold the jib in wor king con di tion
20.5 Ma no e u vres to fold the jib in rest con di tion
20.6 O pe ra tions to re mo ve the hy dra u lic jib from the cra ne
20.7 O pe ra tions to mount the hy dra u lic jib on the cra ne
20.8 Crane with lifting moment limiting device and "Prolink"
(if fitted)
21 WINCH (if fitted)
21.1 Generality (version with lifting moment limiting device)
21.2 Winch for crane (version with lifting moment limiting device)
21.2.1 Winches equipped with a mechanical stroke end device
22 MAINTENANCE INSTRUCTIONS
22.1 Generality
22.2 Timer
22.3 After every 8 working hours or at the end of every working day
22.4 After every 40 working hours or after every working week
22.5 After every 100 working hours or more frequently in case of more intensive utilisation
22.6 After every 500 working hours or after every 6 working months
22.7 After every 1000 working hours or after every working year
22.8 Complete overhaul of the crane is required when 10.000 working hours or 10 years'life
are reached
22.9 Instructions for the dismantlement and the demolition of a FASSI crane
23 TABLE OF HYDRAULIC OIL AND LUBRICANTS CHA RAC TE RI STI CS
24 POSSIBLE FAULTS
24.1 Generality
24.2 Only operations which can be carried out by the user
24.3 Operations to be carried out only by a service center
25 INSTRUCTION AND WARNING PLATES
