16.6 "Rotation limiting device"
When a sector of the working area exists in which the stability is insufficient
(for example in the area in front of the cab) the permitted arc of rotation is limi-
ted by means of an adjustable electro-hydraulic device which only allows ope-
ration within the safe area.
When exceeding the "safe area" the rotation limiting device only allowing:
- the opposite rotation
- the manoeuvres allowed by the limiting device.
16.7 Setting menu
How to visualise the data
· Press the clock button to have the current date visualized on display
How to activate the timer:
<< Partial timer >>:
· Start from the main screen showing pressures in the lifting rams, and
select the "CLOCK" icon until "TIME"is displayed
· select the icon : "Partial Time" is displayed,
· select the icon "ENTER" to read the value on the timer.
· To reset the partial time, do as follows:
· keep the icon pressed until you read "TIME" on the display,
· select the icon to read "Partial Time" on the display,
· select again the icon : "Total Time" is displayed,
· select again the icon : "Work Time" s displayed,
· select again the icon : "Reset Partial" is displayed,
· select the icon to read "Enter to Confirm" on the display,
· select again : the timer is reset and it will start recording again.
<< Total Time (total activation time of the electric panel)>>:
· Start from the main screen and select the "CLOCK" : icon until
"TIME" is displayed,
· select the icon : "Partial Time" is displayed,
· select again the icon : "Total Time" is displayed,
· select the icon "ENTER" to visualize, for about 5 seconds, the
total time expressed in hours and minutes.
<< Work Time (total crane work time linked to the activation of the levers) >>:
· Start from the main screen and select the "CLOCK" icon until
"TIME" is displayed,
· select the icon : "Partial Time" is displayed,
· select again the icon : "Total Time" is displayed,
· select again the icon "Work Time" is displayed,
· select the icon "ENTER" to visualize, for about 5 seconds, the
total work time expressed in hours and minutes.
16.6
CONTROLS TO OPERATE
THE CRANE
GR4_5 - EVOLUTION
