-6-
• Although precaution is only a Attention, a serious result could be caused depending on the
situation. Please follow safety precautions.
• Checking the product
Check if the product is damaged or parts are missing.
Otherwise, the machine may get damaged or the user may get injured.
Semiconductor device was used in Drive. Be careful handling.
Static electricity will result in the drive damage.
Motor and drive are sure to ground for prevent product damage from electric
shock or static electricity.
• Installing
Please carry the Ezi-SPEED carefully.
Otherwise, the product may get damaged or user’s foot may get injured by
dropping the product.
Use non-flammable materials such as metal in the place where the Ezi-
SPEED is to be installed.
Otherwise, a fire may occur.
When installing several Ezi-SPEED in a sealed place, install a cooling fan to
keep the ambient temperature of the product as 40℃ or lower.
Overheating may cause fore or other accidents.
Installation, connection, operation, inspection and troubleshooting should
be carried out by qualified personnel.
Otherwise, a fire or other kinds of accidents may occur.
• Wiring
Keep the rated range of input voltage for Ezi-SPEED drive.
Otherwise, a fire or other kinds of accidents may occur.
Cable connection should be following the wiring diagram.
Otherwise, a fire or malfunction of machine may occur.
Connecting the motor and drive
