Mode
1 Side Settings Level Control = 3 The higher the value, the less expansion in the
drink.
2 Side Settings The lower the value, the greater the expansion in
the drink.
3 Side Settings The lower the value, the harder and colder the
drink.
4 Side Settings
Thaw/Freeze = 10 The higher the value, the higher the drink
temperature.
The lower the value, the lower the drink
temperature.
For more frozen, use lower values.
For more liquid or less frozen, use higher values.
Test for proper drink temperature (24°F to
28°F) before adjusting.
FUB MODE = OFF This will allow customer to use a FUB product
and not inject CO2 into product. Default setting
is “OFF”. Select “ON” to initiate the mode.
Common Settings Serial # Default setting is 999999. Serial number of the unit
will be placed inside menu if Bevtrak is to be used
on the unit.
Voltage Offset = 0 Use this offset to match the “Line Voltage” readout
(in “Common Readouts”) to the actual incoming
voltage measured with a voltmeter at L1 and L2 of
the contactor (see Section 6.1 and Figure 6.3).
This must be completed prior to starting machine for operation.
1. Measure, with a voltmeter, incoming line voltage at L1 and L2 of contactor and record.
2. Read LCD “Line Voltage” reading under READOUTS - Common Readouts and compare
with voltmeter reading. [If within two (2) volts, skip Steps 3 and 4.]
3. Using Voltage Offset, enter valve that will allow LCD Line Voltage readout to match the
voltmeter reading.
4. Once this is set, the machine is ready to run.
NOTE:
In the FBD562 unit, the 1 Side and 2 Side equate respectively to the Left Side and Right Side;
and in the FBD563 unit, the 1 Side, 2 Side, and 3 Side equate respectively to the Left Side,
Center, and Right Side. In the FBD564 unit, the 1,2, 3 and 4 sides are from left to right. (See
Figures 7.1.a and 7.1.b and 7.1.c.)
7.3 MACHINE SETTINGS
These settings are preset by the machine. DO NOT change unless there is a problem with
drink quality.
20
