14.3 MOUNTING DIAGRAM - FBD 564
This Figure illustrates the locations of threaded mounting holes in the base of the FBD564 unit.
26.0”
CENTER
LINE
4 x 1/2”
CLEARANCE
HOLE
23.875
1.75”
10.3”
FRONT
20.0”
32.4”
7.125”
DRAIN
8.500”
DRIPTRAY
EDITOR’S NOTE: NOT DRAWN TO SCALE
44
