Felder Hammer - Page 41

Check the alignment of the extension table at it’s mounting points and at the
extremity of the table.
Test Point Unit type Tolerance
Parallel to the table it is mounted on Metric 0.0mm to 0.40mm
(below mounting table) Imperial 0.000” to 0.016”
Alignments
EX01 Additional Extension Tables
