Felder Hammer - SS08 Angled Cut from Outrigger

Check the alignment of the 45° position on the outrigger angle scale.
Test Point Unit type Tolerance
From point 1 to 2 Metric +/- 0.1mm
(From 1000mm x 500mm, 45° angle) Imperial +/- 0.004”
Alignments
Adju s t m e n t Lin k
SS08 Angled Cut From Outrigger
