Felder Hammer - PL01 Planer Test

Check the thickness of workpieces 1 and 2 with vernier calipers.
Test Point Unit type Tolerance
310mm table, thickness difference from 1 to 2 Metric +/- 0.10mm
Imperial +/- 0.004”
410mm table, thickness difference from 1 to 2 Metric +/- 0.015mm
Imperial +/- 0.006”
Alignments
Adju s t m e n t Lin k
PL01 Planer Test
