Felder Hammer - Sliding Table Alignment Procedures

Sliding table should be further away from the blade at position 2
Test Point Unit type Tolerance
Increase from 1 to 2 of Metric 0.05mm to 0.10mm
(over Ø300mm Saw Blade) Imperial 0.002” to 0.004”
Alignments
Adju s t m e n t Lin k
SS01 Free cut from the Sliding Table
No Dial Indicator?
