Felder Hammer - SR08 Alignment of the Saw Blade at

Using to two workpieces, place the 45° cuts together to create a miter joint. Using an
engineers square, 200mm long, check for any space at positions 1 and 2.
Test Point Unit type Tolerance
Permissable gap per 200mm Metric 0.00mm to 0.20mm
Imperial 0.000” to 0.008”
Alignments
Adju s t m e n t Lin k
SR08 Saw Blade Alignment at 45°
