Fema C Series User Manual

FEMA ELECTRÓNICA . Series C . C40-D
25
1.31 Precauons on installaon
1.32 Factory conguraon
This instrument is warranted against all manufacturing defects for a period
of 24 months, as requested by the European legislaon. This warranty does
not apply in case of misuse or accident, and the scope of the warranty is lim-
ited to repair of the instrument, not being the manufacturer responsible for
addional damages or addional costs. Within the warranty period and aer
examinaon by the manufacturer, the unit will be repaired or substuted
when found to be defecve.
Extended warranty available at www.fema.es / docs / 4153_Warranty1_
en.
pdf
1.33 Warranty
Range 600 Vac
Scaling and decimal point 0/600 Vac = 0/600
Alarms 1
Type alarm as maximum
Setpoint 1000
Hysteresis 0 counts
Alarm 2
Type alarm as maximum
Setpoint 1000
Hysteresis 0 counts
External control o
Fast access all o
Tools
Opon.1 o (retains last conguraon value)
Step 1
Average 0
Oset reading 0
Second scaling 0/600
‘Eco’ mode o
Temperature resoluon 1º
Degrees ºC
Alpha 385
cJc on
AC deadband 20
Brightness 3
Password o
Opon 1 conguraon
Opon analog output 0/100.0=4/20 mA
Opon serial Modbus RTU 9600 bps, address 1, format 8n1
Jumpers ‘S’ selected for 600 Vac
Jumper ‘T’ selected for ‘EK’ external control funcon
1.34 CE declaraon of conformity
Manufacturer FEMA ELECTRÓNICA, S.A.
Almira 14 - Pol. Ind. Sanga
E08210 - Barberà del Vallès
BARCELONA - SPAIN
www.fema.es - info@fema.es
Products C40-D
The manufacturer declares that the instruments indicated comply with the
direcves and rules indicated below.
Electromagnec compability direcve 2014/30/EU
Low voltage direcve 2014/35/EU
ROHS direcve 2011/65/EU
WEEE direcve 2012/19/EU
Security rules EN-61010-1
Instrument Fixed, Permanently connected
Polluon degree 1 and 2 (without condensaon)
Isolaon Double
Category CAT-III up to 300V
CAT-II up to 600V (only with ‘Polluon degree 1’)
Electromagnec compability rules EN-61326-1
EM environment Industrial
CISPR 11 Instrument Class A & Class B Group 1
For a detailed declaraon see document www.fema.es / docs / 4152_CE-
Declaraon_C40-D_en.pdf
Barberà del Vallès, January 2017
Xavier Juncà - Product Manager
According to direcve 2012/19/EU, electronic equip-
ment must be recycled in a selecve and controlled
way at the end of its useful life.
This instrument has been designed and veried conforming to the 61010-1 CE Security
Regulaon, for industrial applicaons. Installaon of this instrument must be performed
by qualied personnel only. This manual contains the appropriate informaon for the in
-
stallaon. Using the instrument in ways not specied by the manufacturer may lead to a
reducon of the specied protecon level. Disconnect the instrument from power before
starng any maintenance and / or installaon acon.
The instrument does not have a general switch and will start operaon as soon as power is
connected. The instrument does not have protecon fuse, the fuse must be added during
installaon.
The instrument is designed to be panel mounted. An appropriate venlaon of the in-
strument must be assured. Do not expose the instrument to excess of humidity. Maintain
clean by using a humid rag and do NOT use abrasive products such as alcohols, solvents,
etc. General recommendaons for electrical installaons apply, and for proper funconal
-
ity we recommend : if possible, install the instrument far from electrical noise or magnec
eld generators such as power relays, electrical motors, speed variators, ... If possible, do
not install along the same conduits power cables (power, motor controllers, electrovalves,
...) together with signal and/or control cables. Before proceeding to the power connecon,
verify that the voltage level available matches the power levels indicated in the label on
the instrument. In case of re, disconnect the instrument from the power line, re alarm
according to local rules, disconnect the air condioning, aack re with carbonic snow,
never with water.
Risk of electrical shock. Instrument terminals can be connected
to dangerous voltage.
Instrument protected with double isolaon. No earth connecon
required.
Instrument conforms to CE rules and regulaons.
