FEMA ELECTRÓNICA . Series C . C40-D
21
1.29 Conguraon menu (cont.)
At the ‘Opon 1 conguraon’ (‘out.1’) congure the module in-
stalled at slot Opt.1. This menu varies depending on the module in-
stalled (relay, analog output or serial output). The type of module
installed is indicated at the menu ‘Tools’ / ‘out.1’.
• ‘Analog output’ (‘420’) : select ‘analog output’ (‘420’) at ‘Tools’
/ ‘out.1’ / ‘420’, to have the analog output conguraon at this
menu entry. Introduce the reading value associated to 4 mA (Dis-
play Low (‘d.Lo’)) and the reading value associated to 20 mA (Dis-
play High (‘d.Hi’))
• ‘Modbus RTU’ (‘r.485’) : select ‘Modbus RTU’ (‘r.485’) at ‘Tools’
/ ‘out.1’ / ‘r.485’, to have the serial output conguraon at this
menu entry. Congure the address for the instrument (parameter
‘Address 1 to 247’ (‘Addr’)), the bus speed (parameter ‘Speed
kbps’ (‘bAud’)) congurable to 9.600 bps or 4.800 bps, and the
bus format (parameter ‘Format’ (‘bItS’)) congurable at 8n1, 8E1,
8o1 or 8n2.
The slot at Opt.2 allows only for a relay module, and conguraon is
done through the menu entry ‘Alarm 2’ (‘ALr2’).
1.29.8 Conguring the opons
• At the ‘Factory reset’ (‘FAct’) menu, select ‘yes’ to load the de-
fault factory conguraon for the instrument. See secon 1.32
for a list of values at default factory conguraon.
Factory reset
Opon 1
conguraon*
(*value selected
at /Tool/Out.1)
Analog output
Display Low
Display High
Modbus RTU
Address 1 to 247
Speed Kbps
Format
