Fender RUMBLE STAGE 800 User Manual

GLOBAL SETTINGS
As noted, GLOBAL SETTINGS is used to assign the EXP-1 to all presets. After pressing the MENU utility button
and scrolling to and selecting “EXP-1 SETUP,” press the ENCODER again and scroll to “GLOBAL SETTINGS” (see
illustration below).
Press the ENCODER on “GLOBAL SETTINGS.” Three parameters can be modied in the menu shown—”MODE
SOURCE,” “HEEL VOLUME” and “TOE VOLUME.” “MODE SOURCE” is used to choose between “PRESET” and
“PEDAL” settings. “PRESET” means that whatever preset the user is in determines whether the EXP-1 is in
Volume mode or Expression mode (this can change from preset to preset). In the “PEDAL” setting, the EXP-1
overrides preset settings and stays in whichever mode (Volume or Expression) it’s currently in.
Press the ENCODER and turn it to select “PEDAL” or “PRESET.” The label box will change from blue to red (see
illustration below) until a selection is made by pressing the ENCODER again, after which the label box will
return to blue with the current selection in place.
“HEEL VOLUME” and “TOE VOLUME” are used together to set a volume range covered by the pedal, the
default range of which is set at 1-10, with the heel all the way down being 1 (no volume) and the toe all the
way down being 10 (full volume). This range can be adjusted to preference, by using the “HEEL VOLUME”
control to set a dierent value for minimum volume and using the “TOE VOLUME” control to set a dierent
value for maximum volume.
Use the ENCODER to scroll to and select the “HEEL VOLUME” and “TOE VOLUME” controls. When each is select-
ed, it will turn from blue to red, indicating that it can now be adjusted. When adjustment is complete, press
the ENCODER again to keep the new control value, and the control will return to blue (see illustration below).
Note that Global Settings changes are saved automatically; no extra “save” step is required.
56
MENU
GLOBAL SETTINGS
PRESET SETTINGS
back
SAVE
MENU
HEEL TOE
PRESET
MODE SOURCE
SAVE
EXP-1 (GLOBAL)
back
MENU
MODE SOURCE HEEL TOE
PRESET
SAVE
EXP-1 (GLOBAL)
back
