Fermax 60305 - Power Supply Installation

Pag 36
KIT
VIDEOPORTERO DIGITAL 5 HILOS
VIDEOPORTERO DIGITAL 5 HILOS
POWER SUPPLY INSTALLATION
The Power Supply must be fitted in a dry and sheltered place. The DIN 6 format lets you
install it in any junction box or directly onto the wall using the plugs and screws supplied.
VERY IMPORTANT NOTE
99
99
9 The Power Supply must always be installed indoors. It may be placed inside a
DIN electrical switch box.
Current legislation demands the installation must be protected by means of a
magnetothermal switch at the power point.
Dismantling
DIN rail installation.
Assembly
Fitting with screws.
+18V 1.5A
5
0
-6
0
H
z
.
50
V
A
M
A
X
.
12V 1A
FU
EN
TE A
LIM
EN
TA
CIO
N
K
I
T
D
I
G
I
T
A
L
M
A
D
E
I
N
S
P
A
I
N
