VIDEOPORTERO DIGITAL 5 HILOS
VIDEOPORTERO DIGITAL 5 HILOS
OUTDOOR PANEL INSTALLATION
VERY IMPORTANT NOTE
99
99
9
Before closing the panel, the monitor must be programmed in order to be able
to carry out the final adjustments checking audio and video.
The outdoor panel is sufficently protected against damp and other atmospheric agents.
However, in permanently adverse weather conditions of heavy rainfall or saline
atmosphere it should be installed in a sheltered place to prolong the active life of the
equipment. Strong light directly onto the camera (backlight) will make the image lose
contrast and/or clarity.
Fit the damp-proof cellular rubber
strips supplied.
Use the hinges to fasten the
cables and manipulate the panel
easily (with flush box).
Make the holes needed to pass the
cables through.
Recommended height
Follow the recommendations below for correct installation of the Outdoor Panel.
1.7m
