Fermax MDS Series Technical Book

Pag. 19
Technical Book
MDS
MDS
PC Interface Programming Card Ref. 2427
The MDS-Digital system parameters can be configured via PC, giving the possibility of programming the
system before installing it with all the advantages this provides: installations management (by files), user
lists... FERMAX has developed special software to manage and program the MDS-Digital systems: the
WINCOM. See the Basic and PC MDS Programming Manuals for further details.
By means of this card, it is also possible to change the language of the messages shown in the MDS-
Digital panel display.
MAX. 3m LENGTH
PIN Nº: PIN Nº:
7
3
2
2
3
5
MAX. 3m LENGTH
PIN Nº: PIN Nº:
5
3
2
2
3
5
The cable required to link the PC with the PC Interface Card in Central Unit is not supplied by FERMAX.
You can easily make your own cable depending on the serial connector you want to use (DB9 or DB25).
FXL Central Programming Module Ref. 2338
PC card inserted in its
connector
RX led.
Central Unit receiving data from PC
TX led.
Central Unit sending data to PC
PC cable for FXL
MANAGEMENT
Ref.5918Ref.5918
MDS CENTRAL UNIT
WITH FXL INTERFACE CARD
MDS CENTRAL UNIT
WITH FXL INTERFACE CARD
STANDARD CITYMAX
TELEPHONE REF.8044
220 Vac220 Vac
12V
+
--+
REF. 8840
POWER SUPPLY
ALIMENTADOR
PRIM.
FE
+-
BAT.13.8V
A
B
G
A
B
G
NR-2067
NR-2055
DECODERS
PANEL 1 PANEL 0
12
-++-
DD26CtVM
Ct
M
V
+
-
2
6
SA
SB
6
2
SB
SA
-
+
M
V
CtCt
V
M
+
-
SA
SB
2
6
SB
SA
6
2
-
+
V
M
Ct
MVCt 6 2 DD
-+
+-
21
PANEL 0PANEL 1
DECODERS
NR-2055
NR-2067
G
B
A
G
B
A
BAT.13.8V
-+
EF
PRIM.
ALIMENTADOR
POWER SUPPLY
REF. 8840
+- -+
12V
-
A
PRIM.
GESTION FXL
FXL MANAGEMENT
REF. 2338
B 2 662BA
-
12 34 6
220 Vac
Ref.5922
NR-2086
21 3 54 6
WINCOM
Tx
Rx
Pwr
2427 Card sidePC side
DB-9
2427 Card sidePC side
DB-25
There is another choice for PC programming in MDS-Digital systems which is strongly recommended for
installations with several Central Units. In that particular case, it may be interesting to use a device that
allows the programmer to access every Central Unit from a common point, without it being necessary to
unplug the FXL card (as with the PC Interface Module above).
