BLUEHELIX MAXIMA
19IT
cod. 3541U630 - Rev. 00 - 07/2020
Collegamento a canne fumarie collettive
fig. 21 - Esempi di collegamento a canne fumarie ( = Aria / = Fumi)
fig. 22 - Esempi di collegamento sistema C10 e C11 ( = Aria / = Fumi)
C
8X
C
2X
C
4X
C93C93
C
11
C
11
C
10
C
10
