TECHNICAL DATA - BASE VERSION (VB)
NOMINAL performances - Exta low noise setting up (AX) - Standard plants
NOMINAL performances - Exta low noise setting up (AX) - Standard plants - Data certified by EUROVENT
Data declared according to EN 14511. The values are referred to units without options and accessories.
IR
Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )
Cooling capacity 44,3 52,4 59,1 66,1 78,2 89,0 100 112 125 143 162 184
kW
Power input
15,6 18,1 20,8 23,2 27,9 32,3 36,0 40,4 44,9 51,8 57,8 66,9
kW
EER 2,84 2,90 2,84 2,85 2,80 2,76 2,76 2,77 2,78 2,76 2,80 2,75
-
Water flow rate plant side 2,12 2,51 2,84 3,18 3,75 4,27 4,78 5,40 6,02 6,88 7,79 8,84
l/h
Pressure drops plant side 21 30 29 36 27 28 30 29 31 31 33 34
kPa
IP
Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )
Cooling capacity 42,5 50,3 56,9 63,6 76,2 86,5 97,0 109 120 138 155 179
kW
Power input
15,3 18,0 20,3 22,8 27,4 31,4 35,2 39,6 44,0 50,2 56,7 65,0
kW
EER 2,78 2,79 2,80 2,79 2,78 2,75 2,76 2,75 2,73 2,75 2,73 2,75
-
Water flow rate plant side 2,04 2,41 2,73 3,05 3,66 4,15 4,65 5,21 5,78 6,64 7,45 8,60
l/h
Pressure drops plant side 20 27 27 33 26 27 28 27 29 28 31 32
kPa
Heating A7W45 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 40°C out 45°C )
Heating capacity 47,6 56,1 63,4 71,3 85,0 96,5 109 121 136 155 174 199
kW
Power input
14,7 17,2 19,6 22,2 25,9 29,5 33,3 37,4 42,0 47,7 53,6 61,3
kW
COP 3,24 3,26 3,23 3,21 3,28 3,27 3,27 3,24 3,24 3,25 3,25 3,25
-
Water flow rate plant side 2,26 2,67 3,01 3,38 4,04 4,59 5,16 5,73 6,45 7,36 8,27 9,46
l/h
Pressure drops plant side 24 33 33 41 32 32 35 32 36 35 38 39
kPa
Heating A2W45 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 40°C out 45°C )
Heating capacity 43,5 51,4 58,1 65,3 77,8 88,5 99,6 110 124 142 159 183
kW
Power input
15,0 17,6 20,0 22,7 26,4 30,1 34,0 38,3 42,9 48,7 54,8 62,6
kW
COP 2,90 2,92 2,91 2,88 2,95 2,94 2,93 2,87 2,89 2,92 2,90 2,92
-
Water flow rate plant side 2,30 2,71 3,07 3,44 4,11 4,67 5,26 5,83 6,55 7,50 8,41 9,65
l/h
Pressure drops plant side 25 35 34 42 33 34 36 34 37 36 39 41
kPa
IR
Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )
Cooling capacity 44,4 52,6 59,4 66,5 78,5 89,4 100 113 126 144 163 185
kW
EER 2,86 2,94 2,90 2,92 2,84 2,80 2,82 2,83 2,84 2,82 2,86 2,81
-
Water flow rate plant side 21 30 29 36 27 28 30 29 31 31 33 34
kPa
ESEER 4,53 4,64 4,58 4,61 4,49 4,55 4,45 4,60 4,49 4,58 4,53 4,44
-
IP
Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )
Cooling capacity 42,6 50,5 57,1 63,9 76,5 86,9 97,4 109 121 139 156 180
kW
EER 2,80 2,84 2,84 2,84 2,82 2,80 2,80 2,79 2,79 2,80 2,79 2,81
-
Water flow rate plant side 20 27 27 33 26 27 28 27 29 28 31 32
kPa
ESEER 4,43 4,48 4,49 4,49 4,46 4,55 4,42 4,53 4,41 4,55 4,41 4,44
-
Riscaldamento A7W45 ( sorgente : aria in 7°C b.s. 6°C b.u. / impianto : acqua in 40°C out 45°C )
Heating capacity 47,4 55,8 63,1 70,8 84,6 96,0 108 120 135 154 173 198
kW
COP 3,27 3,30 3,27 3,26 3,32 3,31 3,30 3,26 3,28 3,29 3,29 3,29
-
Water flow rate plant side 24 33 33 41 32 32 35 32 36 35 38 39
kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Power supply
400 - 3+N - 50 400 - 3 - 50
V-ph-Hz
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Power supply
400 - 3+N - 50 400 - 3 - 50
V-ph-Hz
