TECHNICAL DATA - BASE VERSION (VB)
Mod. 40.2 ÷ 100.2
Tw= Outlet water temperature °C
kWf = Cooling capacity (kW)
kWa = Compressor power input (kW)
kWt = Heating capacity (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the heat exchanger and to operation of the unit with all fans at
nominal or maximum speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
The performances are declared no considering any correction due to water flow rate and water side pressure drop (gross performance).
Standard performances in cooling mode IP - Base setting up (AB)
(1) : at these temperatures the fans are at maximum speed.
(2) : ATC (Advanced Temperature Control) function may occur, if present.
MOD.
TW
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50 (2)
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
40.2
5 51,6 9,1 48,7 10,4 45,9 11,7 43,0 13,0 40,1 14,3 37,3 15,6 34,4 16,9
6 53,1 9,2 50,1 10,5 47,2 11,8 44,3 13,1 41,3 14,4 38,4 15,7 35,4 17,0
7 54,6 9,2 51,6 10,6 48,5 11,9 45,5 13,2 42,5 14,5 39,4 15,8 36,4 17,2
8 56,1 9,3 53,0 10,6 49,9 12,0 46,7 13,3 43,6 14,6 40,5 16,0 - -
9 57,6 9,4 54,4 10,7 51,2 12,1 48,0 13,4 44,8 14,7 41,6 16,1 - -
10 59,1 9,4 55,8 10,8 52,5 12,1 49,2 13,5 45,9 14,8 42,7 16,2 - -
11 60,6 9,5 57,2 10,9 53,8 12,2 50,5 13,6 47,1 14,9 43,8 16,3 - -
12 62,0 9,6 58,6 10,9 55,2 12,3 51,7 13,7 48,2 15,0 44,8 16,4 - -
50.2
5 61,2 10,8 57,7 12,3 54,4 13,8 51,0 15,4 47,5 16,9 44,2 18,4 40,8 20,0
6 62,9 10,8 59,4 12,4 55,9 13,9 52,4 15,5 48,9 17,0 45,5 18,6 41,9 20,1
7 64,7 10,9 61,1 12,5 57,5 14,0 53,9 15,6 50,3 17,2 46,7 18,7 43,1 20,3
8 66,4 11,0 62,7 12,6 59,1 14,1 55,4 15,7 51,7 17,3 48,0 18,9 - -
9 68,2 11,1 64,4 12,7 60,6 14,2 56,8 15,8 53,0 17,4 49,3 19,0 - -
10 70,0 11,2 66,1 12,8 62,2 14,3 58,3 15,9 54,4 17,5 50,6 19,1 - -
11 71,7 11,2 67,7 12,8 63,8 14,4 59,8 16,1 55,8 17,7 51,8 19,3 - -
12 73,5 11,3 69,4 12,9 65,4 14,6 61,3 16,2 57,1 17,8 53,1 19,4 - -
60.2
5 69,2 11,9 65,3 13,6 61,5 15,3 57,7 17,0 53,8 18,8 50,0 20,5 46,1 22,2
6 71,2 12,0 67,2 13,7 63,3 15,5 59,3 17,2 55,4 18,9 51,4 20,6 47,5 22,3
7 73,2 12,1 69,1 13,8 65,1 15,6 61,0 17,3 56,9 19,0 52,9 20,8 48,8 22,5
8 75,2 12,2 71,0 13,9 66,9 15,7 62,7 17,4 58,5 19,2 54,3 20,9 - -
9 77,2 12,3 72,9 14,0 68,6 15,8 64,3 17,6 60,0 19,3 55,8 21,1 - -
10 79,2 12,4 74,8 14,1 70,4 15,9 66,0 17,7 61,6 19,4 57,2 21,2 - -
11 81,2 12,5 76,7 14,2 72,2 16,0 67,7 17,8 63,1 19,6 58,7 21,4 - -
12 83,2 12,6 78,5 14,3 74,0 16,1 69,3 17,9 64,7 19,7 60,1 21,5 - -
70.2
5 77,4 13,5 73,1 15,4 68,8 17,3 64,5 19,2 60,2 21,1 55,9 23,1 51,6 25,0
6 79,6 13,6 75,2 15,5 70,8 17,4 66,3 19,4 61,9 21,3 57,5 23,2 53,1 25,2
7 81,8 13,7 77,3 15,6 72,8 17,6 68,2 19,5 63,6 21,5 59,1 23,4 54,6 25,4
8 84,1 13,7 79,4 15,7 74,8 17,7 70,1 19,6 65,4 21,6 60,7 23,6 - -
9 86,3 13,8 81,5 15,8 76,7 17,8 71,9 19,8 67,1 21,8 62,4 23,7 - -
10 88,5 13,9 83,6 15,9 78,7 17,9 73,8 19,9 68,8 21,9 64,0 23,9 - -
11 90,8 14,0 85,7 16,1 80,7 18,1 75,6 20,1 70,6 22,1 65,6 24,1 - -
12 93,0 14,1 87,8 16,2 82,7 18,2 77,5 20,2 72,3 22,2 67,2 24,3 - -
80.2
5 92,7 15,7 87,5 17,9 82,4 20,1 77,2 22,4 72,1 24,6 67,0 26,8 61,8 29,1
6 95,4 15,8 90,0 18,0 84,8 20,3 79,5 22,5 74,1 24,8 68,9 27,0 63,6 29,3
7 98,0 15,9 92,6 18,2 87,2 20,4 81,7 22,7 76,2 25,0 70,8 27,2 65,4 29,5
8 101 16,0 95,1 18,3 89,6 20,6 83,9 22,9 78,3 25,2 72,8 27,4 - -
9 103 16,1 97,6 18,4 91,9 20,7 86,2 23,0 80,4 25,3 74,7 27,6 - -
10 106 16,2 100 18,6 94,3 20,9 88,4 23,2 82,5 25,5 76,6 27,8 - -
11 109 16,4 103 18,7 96,7 21,0 90,6 23,4 84,5 25,7 78,6 28,0 - -
12 111 16,5 105 18,8 99,1 21,2 92,8 23,5 86,6 25,9 80,5 28,2 - -
90.2
5 105 18,1 99,4 20,7 93,6 23,2 87,7 25,8 81,9 28,4 76,1 31,0 70,2 33,6
6 108 18,2 102 20,8 96,3 23,4 90,3 26,0 84,2 28,6 78,3 31,2 72,2 33,8
7 111 18,3 105 21,0 99,0 23,6 92,8 26,2 86,6 28,8 80,5 31,4 74,2 34,1
8 114 18,5 108 21,1 102 23,8 95,3 26,4 88,9 29,0 82,7 31,7 - -
9 117 18,6 111 21,3 104 23,9 97,9 26,6 91,3 29,2 84,8 31,9 - -
10 120 18,7 114 21,4 107 24,1 100 26,8 93,7 29,4 87,0 32,1 - -
11 124 18,9 117 21,6 110 24,3 103 27,0 96,0 29,7 89,2 32,4 - -
12 127 19,0 119 21,7 113 24,4 105 27,2 98,4 29,9 91,4 32,6 - -
100.2
5 118 20,5 111 23,4 105 26,3 98,3 29,3 91,7 32,2 85,2 35,1 78,7 38,0
6 121 20,6 115 23,6 108 26,5 101 29,5 94,4 32,4 87,7 35,4 80,9 38,3
7 125 20,8 118 23,8 111 26,7 104 29,7 97,0 32,7 90,2 35,6 83,2 38,6
8 128 20,9 121 23,9 114 26,9 107 29,9 99,7 32,9 92,6 35,9 - -
9 132 21,1 124 24,1 117 27,1 110 30,1 102 33,1 95,1 36,2 - -
10 135 21,2 127 24,3 120 27,3 113 30,3 105 33,4 97,5 36,4 - -
11 138 21,4 131 24,5 123 27,5 115 30,6 108 33,6 100 36,7 - -
12 142 21,5 134 24,6 126 27,7 118 30,8 110 33,9 102 36,9 - -
