TECHNICAL DATA - IR RECOVERY VERSION (VR)
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Base setting up AB
Heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Low noise setting up AS
Recovery heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Extra low noise setting up AX
Recovery heat exchanger specifications
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3,61 3,61 4,56 5,42 6,27 5,46 5,93 6,86 7,49 8,74 9,67 10,9 l
Unit specication
Cooling capacity VR (1) 49,3 58,4 65,9 73,8 87,2 99,2 111 126 139 160 181 206 kW
Total power input VR (1) 13,0 15,1 17,0 19,0 22,3 26,0 29,2 33,0 36,9 42,0 47,0 54,0 kW
EER VR (1) 3,79 3,87 3,88 3,88 3,91 3,82 3,80 3,82 3,77 3,81 3,85 3,81 -
Water flow rate VR (1) 2,36 2,79 3,15 3,53 4,17 4,74 5,30 6,02 6,64 7,64 8,65 9,84 l/s
Water pressure drop VR (1) 26 37 36 44 34 35 37 36 38 38 41 42 kPa
Recovered heating capacity (1) 61,7 72,7 82,1 91,9 108 124 139 157 174 200 226 257 kW
Recovered water flow rate (1) 2,95 3,47 3,92 4,39 5,16 5,92 6,64 7,50 8,31 9,56 10,8 12,3 l/s
Recovered water pressure drop (1) 34 47 42 41 48 47 52 49 51 50 54 53 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3,61 3,61 4,56 5,42 6,27 5,46 5,93 6,86 7,49 8,74 9,67 10,9 l
Unit specication
Cooling capacity VR (1) 49,3 58,4 65,9 73,8 87,2 99,2 111 126 139 160 181 206 kW
Total power input VR (1) 13,0 15,1 17,0 19,0 22,3 26,0 29,2 33,0 36,9 42,0 47,0 54,0 kW
EER VR (1) 3,79 3,87 3,88 3,88 3,91 3,82 3,80 3,82 3,77 3,81 3,85 3,81 -
Water flow rate VR (1) 2,36 2,79 3,15 3,53 4,17 4,74 5,30 6,02 6,64 7,64 8,65 9,84 l/s
Water pressure drop VR (1) 26 37 36 44 34 35 37 36 38 38 41 42 kPa
Recovered heating capacity (1) 61,7 72,7 82,1 91,9 108 124 139 157 174 200 226 257 kW
Recovered water flow rate (1) 2,95 3,47 3,92 4,39 5,16 5,92 6,64 7,50 8,31 9,56 10,8 12,3 l/s
Recovered water pressure drop (1) 34 47 42 41 48 47 52 49 51 50 54 53 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3,61 3,61 4,56 5,42 6,27 5,46 5,93 6,86 7,49 8,74 9,67 10,9 l
Unit specication
Cooling capacity VR (1) 49,3 58,4 65,9 73,8 87,2 99,2 111 126 139 160 181 206 kW
Total power input VR (1) 13,0 15,1 17,0 19,0 22,3 26,0 29,2 33,0 36,9 42,0 47,0 54,0 kW
EER VR (1) 3,79 3,87 3,88 3,88 3,91 3,82 3,80 3,82 3,77 3,81 3,85 3,81 -
Water flow rate VR (1) 2,36 2,79 3,15 3,53 4,17 4,74 5,30 6,02 6,64 7,64 8,65 9,84 l/s
Water pressure drop VR (1) 26 37 36 44 34 35 37 36 38 38 41 42 kPa
Recovered heating capacity (1) 61,7 72,7 82,1 91,9 108 124 139 157 174 200 226 257 kW
Recovered water flow rate (1) 2,95 3,47 3,92 4,39 5,16 5,92 6,64 7,50 8,31 9,56 10,8 12,3 l/s
Recovered water pressure drop (1) 34 47 42 41 48 47 52 49 51 50 54 53 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
