TECHNICAL DATA - IP DESUPERHEATER VERSION (VD)
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO UNITS
OPERATING IN THE COOLING MODE.
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO UNITS
OPERATING IN THE COOLING MODE.
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO
UNITS OPERATING IN THE COOLING MODE.
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Base setting up AB
Heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Low noise setting up AS
Heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Extra low noise setting up AX
Heat exchanger specifications
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 47,3 56,1 63,4 70,9 85,0 96,5 108 121 134 154 174 200 kW
Power input compressor VD (1) 12,8 15,1 16,8 18,9 22,0 25,4 28,8 32,6 36,4 41,0 46,6 52,9 kW
Total power input VD (1) 14,0 16,3 18,6 20,7 25,6 29,0 32,4 36,2 40,0 46,4 52,0 60,1 kW
EER VD (1) 3,38 3,44 3,41 3,43 3,32 3,33 3,33 3,34 3,35 3,32 3,35 3,33 -
Water flow rate VD (1) 2,26 2,68 3,03 3,39 4,06 4,61 5,16 5,78 6,40 7,36 8,31 9,56 l/s
Water pressure drop VD (1) 24 34 33 41 32 33 35 33 35 35 38 40 kPa
Recovered heating capacity (1) 13,6 16,2 18,3 20,5 24,5 27,9 31,1 34,7 38,6 44,4 50,1 57,5 kW
Recovered water flow rate (1) 0,65 0,77 0,87 0,98 1,17 1,33 1,49 1,66 1,84 2,12 2,39 2,75 l/s
Recovered water pressure drop (1) 7 9 12 14 20 16 19 11 14 18 23 19 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 45,0 53,4 60,4 67,6 80,9 91,9 103 114 128 147 165 190 kW
Power input compressor VD (1) 13,8 16,2 17,9 20,3 23,6 27,3 30,8 34,9 39,0 43,9 50,0 56,6 kW
Total power input VD (1) 14,6 17,0 19,2 21,5 26,1 29,8 33,4 37,4 41,5 47,7 53,7 61,7 kW
EER VD (1) 3,08 3,14 3,15 3,14 3,10 3,08 3,08 3,05 3,08 3,08 3,07 3,08 -
Water flow rate VD (1) 2,15 2,55 2,89 3,23 3,87 4,39 4,92 5,45 6,12 7,02 7,88 9,08 l/s
Water pressure drop VD (1) 22 31 30 37 29 30 32 29 32 32 34 36 kPa
Recovered heating capacity (1) 13,6 16,2 18,3 20,5 24,5 27,9 31,1 34,7 38,6 44,4 50,1 57,5 kW
Recovered water flow rate (1) 0,65 0,77 0,87 0,98 1,17 1,33 1,49 1,66 1,84 2,12 2,39 2,75 l/s
Recovered water pressure drop (1) 7 9 12 14 20 16 19 11 14 18 23 19 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 44,3 52,5 59,4 66,5 79,6 90,4 101 113 126 145 162 187 kW
Power input compressor VD (1) 14,1 16,6 18,4 20,8 24,2 27,9 31,6 35,8 40,0 45,0 51,1 58,0 kW
Total power input VD (1) 14,8 17,3 19,5 21,8 26,3 30,1 33,8 38,0 42,1 48,2 54,4 62,3 kW
EER VD (1) 2,99 3,03 3,05 3,05 3,03 3,00 2,99 2,97 2,99 3,01 2,98 3,00 -
Water flow rate VD (1) 2,12 2,51 2,84 3,18 3,80 4,32 4,83 5,40 6,02 6,93 7,74 8,93 l/s
Water pressure drop VD (1) 21 30 29 36 28 29 30 29 31 31 33 35 kPa
Recovered heating capacity (1) 13,6 16,2 18,3 20,5 24,5 27,9 31,1 34,7 38,6 44,4 50,1 57,5 kW
Recovered water flow rate (1) 0,65 0,77 0,87 0,98 1,17 1,33 1,49 1,66 1,84 2,12 2,39 2,75 l/s
Recovered water pressure drop (1) 7 9 12 14 20 16 19 11 14 18 23 19 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
