(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Base setting up AB
Heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Low noise setting up AS
Heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Extra low noise setting up AX
Heat exchanger specifications
TECHNICAL DATA - IR DESUPERHEATER VERSION (VD)
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 49,3 58,4 65,9 73,8 87,2 99,2 111 126 139 160 181 206 kW
Power input compressor VD (1) 13,1 15,2 17,2 19,2 22,5 26,3 29,5 33,4 37,2 42,4 47,5 54,5 kW
Total power input VD (1) 14,3 16,4 19,0 21,0 26,1 29,9 33,1 37,0 40,8 47,8 52,9 61,7 kW
EER VD (1) 3,45 3,56 3,47 3,51 3,34 3,32 3,35 3,41 3,41 3,35 3,42 3,34 -
Water flow rate VD (1) 2,36 2,79 3,15 3,53 4,17 4,74 5,30 6,02 6,64 7,64 8,65 9,84 l/s
Water pressure drop VD (1) 26 37 36 44 34 35 37 36 38 38 41 42 kPa
Recovered heating capacity (1) 14,2 16,9 19,0 21,3 25,1 28,6 32,1 36,2 40,3 46,3 52,3 59,4 kW
Recovered water flow rate (1) 0,68 0,81 0,91 1,02 1,20 1,37 1,53 1,73 1,93 2,21 2,50 2,84 l/s
Recovered water pressure drop (1) 7 10 13 16 21 16 20 12 15 20 25 20 kPa
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 47,0 55,7 62,8 70,4 83,1 94,5 106 120 133 153 173 197 kW
Power input compressor VD (1) 14,1 16,3 18,4 20,6 24,1 28,1 31,6 35,7 39,9 45,4 50,9 58,4 kW
Total power input VD (1) 14,9 17,1 19,7 21,8 26,6 30,7 34,1 38,2 42,4 49,2 54,7 63,4 kW
EER VD (1) 3,15 3,26 3,19 3,23 3,12 3,08 3,11 3,14 3,14 3,11 3,16 3,11 -
Water flow rate VD (1) 2,25 2,66 3,00 3,36 3,97 4,52 5,06 5,73 6,35 7,31 8,27 9,41 l/s
Water pressure drop VD (1) 24 33 32 40 31 31 33 32 34 35 38 39 kPa
Recovered heating capacity (1) 14,2 16,9 19,0 21,3 25,1 28,6 32,1 36,2 40,3 46,3 52,3 59,4 kW
Recovered water flow rate (1) 0,68 0,81 0,91 1,02 1,20 1,37 1,53 1,73 1,93 2,21 2,50 2,84 l/s
Recovered water pressure drop (1) 7 10 13 16 21 16 20 12 15 20 25 20 kPa
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 0,55 0,55 0,55 0,55 0,55 0,75 0,75 0,75 1,20 1,20 1,20 1,50 l
Unit specication
Cooling capacity VD(1) 46,2 54,7 61,8 69,2 81,6 93,0 104 118 131 150 170 192 kW
Power input compressor VD (1) 14,4 16,7 18,8 21,0 24,6 28,8 32,3 36,6 40,8 46,5 52,1 59,8 kW
Total power input VD (1) 15,1 17,4 19,9 22,1 26,8 31,0 34,5 38,7 43,0 49,7 55,3 64,1 kW
EER VD (1) 3,06 3,14 3,11 3,13 3,04 3,00 3,01 3,05 3,05 3,02 3,07 3,00 -
Water flow rate VD (1) 2,21 2,61 2,95 3,31 3,90 4,44 4,97 5,64 6,26 7,17 8,12 9,17 l/s
Water pressure drop VD (1) 23 32 31 39 29 30 32 31 33 33 36 37 kPa
Recovered heating capacity (1) 14,2 16,9 19,0 21,3 25,1 28,6 32,1 36,2 40,3 46,3 52,3 59,4 kW
Recovered water flow rate (1) 0,68 0,81 0,91 1,02 1,20 1,37 1,53 1,73 1,93 2,21 2,50 2,84 l/s
Recovered water pressure drop (1) 7 10 13 16 21 16 20 12 15 20 25 20 kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
