Ferroli RGA HE series User Manual

21
NOMINAL performances - Exta low noise setting up (AX) - Standard plants - Data certified by EUROVENT
TECHNICAL DATA - BASE VERSION (VB)
NOMINAL performances - Extra low noise setting up (AX) - Radiant plants
Data declared according to EN 14511. The values are referred to units without options and accessories.
IR
Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )
Cooling capacity 57,4 67,9 76,6 85,7 101 115 129 146 163 185 210 239
kW
Power input 17,0 19,8 22,6 25,3 30,3 35,1 39,1 44,0 49,0 56,5 63,1 73,0
kW
EER 3,38 3,43 3,39 3,39 3,33 3,28 3,30 3,32 3,33 3,27 3,33 3,27
-
Water flow rate plant side 2,76 3,27 3,69 4,13 4,87 5,54 6,21 7,02 7,84 8,93 10,13 11,5
l/h
Pressure drops plant side 36 50 49 61 46 47 50 49 53 52 56 58
kPa
IP
Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )
Cooling capacity 55,1 65,2 73,7 82,4 98,8 112 126 141 156 180 201 232
kW
Power input 16,7 19,7 22,1 24,9 29,8 34,1 38,4 43,0 47,9 54,8 61,9 70,9
kW
EER 3,30 3,31 3,33 3,31 3,32 3,28 3,28 3,28 3,26 3,28 3,25 3,27
-
Water flow rate plant side 2,65 3,14 3,55 3,97 4,75 5,40 6,07 6,78 7,50 8,65 9,70 11,2
l/h
Pressure drops plant side 33 46 45 56 44 45 48 45 48 48 52 55
kPa
Heating A7W35 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C )
Heating capacity 50,4 59,5 67,3 75,5 90,2 103 115 128 144 164 184 211
kW
Power input 12,0 14,1 16,0 18,1 21,3 24,2 27,3 30,5 34,3 39,1 44,0 50,5
kW
COP 4,20 4,22 4,21 4,17 4,23 4,26 4,21 4,20 4,20 4,19 4,18 4,18
-
Water flow rate plant side 2,40 2,82 3,20 3,58 4,29 4,87 5,45 6,07 6,83 7,79 8,74 10,03
l/h
Pressure drops plant side 27 37 37 46 36 36 39 36 40 39 42 44
kPa
Heating A2W35 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 30°C out 35°C )
Heating capacity 46,1 54,6 61,6 69,2 82,6 94,2 105 118 131 150 170 194
kW
Power input 12,2 14,4 16,4 18,6 21,7 24,7 27,8 31,3 35,0 40,0 44,9 51,4
kW
COP 3,78 3,79 3,76 3,72 3,81 3,81 3,78 3,77 3,74 3,75 3,79 3,77
-
Water flow rate plant side 2,44 2,88 3,25 3,65 4,36 4,97 5,54 6,21 6,93 7,93 8,93 10,2
l/h
Pressure drops plant side 28 39 38 48 37 38 40 38 41 41 44 45
kPa
Frame 1 2 3 4
Model 40.2 50.2 60.2 70.2 80.2 90.2 100.2 115.2 130.2 145.2 160.2 180.2
U.M.
Power supply
400 - 3+N - 50 400 - 3 - 50
V-ph-Hz

Ferroli RGA HE series Specifications
