MOD. 350.5 390.6 440.6 490.6 560.6 630.6 UM
IR
Cooling mode A35W7 (source: air 35°C d.b. / system: water in 12°C out 7°C)
Cooling capacity 348 371 436 489 554 619 kW
Compressor power input 109 117 134 156 171 197 kW
Total power input
123 131 152 174 193 219 kW
EER 2.83 2.83 2.87 2.81 2.87 2.83 -
Water ow rate 16.8 17.9 21.0 23.6 26.7 29.9 l/s
Water pressure drop 47 54 48 60 45 56 kPa
IP
Cooling mode A35W7 (source: air 35°C d.b. / system: water in 12°C out 7°C)
Cooling capacity 339 361 423 476 536 603 kW
Compressor power input 106 116 137 157 177 202 kW
Total power input 120 130 151 171 191 216 kW
EER 2.83 2.78 2.80 2.78 2.81 2.79 -
Water ow rate 16.3 17.4 20.4 22.9 25.8 29.0 l/s
Water pressure drop 45 51 45 57 42 53 kPa
Heating mode A7W45 (source: air 7°C d.b. 6°C w.b. / system: water in 40°C out 45°C)
Heating capacity 373 397 460 521 580 664 kW
Compressor power input 109 118 138 160 178 209 kW
Total power input
123 132 152 174 192 223 kW
COP 3.03 3.01 3.03 2.99 3.02 2.98 -
Water ow rate 17.7 18.8 21.8 24.7 27.5 31.4 l/s
Water pressure drop 53 59 51 66 48 62 kPa
Heating mode A2W45 (source: air 2°C d.b. 1°C w.b. / system: water in 40°C out 45°C)
Heating capacity 316 336 389 441 491 562 kW
Compressor power input 108 116 132 155 169 199 kW
Total power input 122 131 150 173 190 221 kW
COP 2.59 2.56 2.59 2.55 2.58 2.54 -
Water ow rate 16.6 17.7 20.5 23.2 25.9 29.6 l/s
Water pressure drop 46 53 45 58 42 55 kPa
Standard unit AB - MEDIUM TEMPERATURE PLANT - Data declared according to UNI EN 14511
Data declared according to UNI EN 14511. The values are referred to units without options and accessories.
Heating capacity takes into account defrosting period.
MOD. 350.5 390.6 440.6 490.6 560.6 630.6 UM
IR
Cooling mode A35W18 (source: air 35°C d.b. / system: water in 23°C out 18°C)
Cooling capacity 444 472 555 622 706 788 kW
Compressor power input 117 128 146 170 186 214 kW
Total power input
131 142 164 188 208 236 kW
EER 3.39 3.32 3.38 3.31 3.39 3.34 -
Water ow rate 21.5 22.9 26.8 30.2 34.1 38.2 l/s
Water pressure drop 77 88 78 98 73 91 kPa
IP
Cooling mode A35W18 (source: air 35°C d.b. / system: water in 23°C out 18°C)
Cooling capacity 431 460 539 605 684 767 kW
Compressor power input 115 125 144 167 183 211 kW
Total power input
130 139 162 185 205 233 kW
EER 3.32 3.31 3.33 3.27 3.34 3.29 -
Water ow rate 20.9 22.3 26.1 29.4 33.0 37.2 l/s
Water pressure drop 73 83 74 93 68 87 kPa
Heating mode A7W35 (source: air 7°C d.b. 6°C w.b. / system: water in 30°C out 35°C)
Heating capacity 378 402 466 528 588 673 kW
Compressor power input 89.0 96.1 109 128 139 165 kW
Total power input
103 110 127 146 160 186 kW
COP 3.67 3.65 3.67 3.62 3.68 3.62 -
Water ow rate 17.9 19.0 22.1 25.0 27.9 31.8 l/s
Water pressure drop 54 61 53 67 49 63 kPa
Heating mode A2W35 (source: air 2°C d.b. 1°C w.b. / system: water in 30°C out 35°C)
Heating capacity 320 340 394 447 497 570 kW
Compressor power input 87.9 94.9 108 126 137 162 kW
Total power input
102 109 126 144 159 184 kW
COP 3.14 3.12 3.13 3.10 3.13 3.10 -
Water ow rate 16.8 17.9 20.7 23.5 26.2 29.9 l/s
Water pressure drop 47 54 46 60 43 56 kPa
Standard unit AB - LOW TEMPERATURE PLANT - Data declared according to UNI EN 14511
Data declared according to UNI EN 14511. The values are referred to units without options and accessories.
Heating capacity takes into account defrosting period.
NOMINAL PERFORMANCES
