STANDARD PERFORMANCES - IR COOLING UNIT ONLY
Tw= Outlet water temperature °C kWf = Cooling capacity (kW). kWa = Compressor power input (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the heat exchanger and to operation of the unit with all fans at
nominal or maximum speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
The performances are declared no considering any correction due to water flow rate and water side pressure drop (gross performance).
Performances - Standard unit AB
MOD.
TW
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 (1) 50 (1) (2)
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
350.5
5
401 73.7 374 84.8 354 93.4 332 103 309 113 286 124 263 134
6
412 74.4 384 85.6 363 94.3 341 104 317 115 294 125 270 135
7
424 75.1 396 86.4 374 95.2 351 105 327 116 302 126 278 136
8
436 76.0 407 87.4 385 96.3 361 106 336 117 311 128
- -
9
448 76.7 418 88.3 395 97.3 371 107 345 118 320 129
- -
10
460 77.5 429 89.1 406 98.2 381 108 354 119 328 130
- -
11
471 78.2 440 90.0 416 99.2 390 109 363 121 336 131
- -
12
484 79.0 452 90.9 427 100 401 110 373 122 346 133
- -
390.6
5
427 80.0 398 92.0 377 101 354 112 329 123 305 134 280 145
6
439 80.7 410 92.9 387 102 363 113 338 124 313 136 288 147
7
452 81.6 421 93.8 399 103 374 114 348 126 322 137 296 148
8
464 82.5 433 94.9 410 105 385 115 358 127 331 139
- -
9
477 83.3 445 95.8 421 106 395 116 368 128 341 140
- -
10
490 84.1 457 96.8 432 107 406 118 377 130 350 141
- -
11
502 84.9 469 97.7 443 108 416 119 387 131 359 143
- -
12
516 85.8 482 98.7 455 109 427 120 398 132 368 144
- -
440.6
5
501 91.9 468 106 442 117 415 128 386 142 358 154 329 167
6
515 92.8 481 107 455 118 427 130 397 143 368 156 338 168
7
530 93.7 495 108 468 119 439 131 408 144 378 157 347 170
8
545 94.8 509 109 481 120 451 132 420 146 389 159
- -
9
560 95.7 523 110 494 121 464 134 432 147 400 161
- -
10
575 96.7 537 111 507 123 476 135 443 149 410 162
- -
11
590 97.6 550 112 520 124 488 136 454 150 421 164
- -
12
606 98.6 565 113 535 125 502 138 467 152 432 166
- -
490.6
5
564 106 526 122 498 134 467 148 435 163 402 178 370 192
6
579 107 541 123 511 136 480 149 447 165 414 180 380 194
7
596 108 557 124 526 137 494 151 460 166 426 181 391 196
8
613 109 572 126 541 138 508 153 473 168 438 183
- -
9
630 110 588 127 556 140 522 154 486 170 450 185
- -
10
647 111 604 128 571 141 536 156 499 172 462 187
- -
11
663 113 619 129 586 143 550 157 511 173 474 189
- -
12
681 114 636 131 601 144 564 159 525 175 486 191
- -
560.6
5
637 118 595 136 562 149 528 165 491 182 455 198 418 214
6
655 119 611 137 578 151 542 166 504 183 467 200 429 216
7
674 120 629 138 595 152 558 168 519 185 481 202 442 218
8
693 122 647 140 611 154 574 170 534 187 494 204
- -
9
712 123 664 141 628 156 590 172 549 189 508 206
- -
10
731 124 682 143 645 157 605 173 563 191 522 208
- -
11
749 125 699 144 661 159 621 175 578 193 535 210
- -
12
770 126 718 145 679 160 638 177 593 195 549 212
- -
630.6
5
713 134 666 154 630 170 591 187 550 206 509 225 468 243
6
733 135 684 156 647 171 607 189 565 208 523 227 481 246
7
755 137 704 157 666 173 625 191 581 211 539 230 495 248
8
776 138 724 159 685 175 643 193 598 213 554 232
- -
9
797 140 744 161 704 177 660 195 614 215 569 234
- -
10
818 141 764 162 722 179 678 197 631 217 584 237
- -
11
839 142 783 164 741 180 695 199 647 219 599 239
- -
12
862 144 805 165 761 182 714 201 664 221 615 241
- -
(1) : at these temperatures the fans are at maximum speed.
(2) : ATC (Advanced Temperature Control) function may occur.
