GENERAL SPECIFICATIONS - VERSION WITH DESUPERHEATER (VD)
IR COOLING UNIT ONLY
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Acoustic Version: AB (Standard Unit)
Recovery heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Acoustic Version: AS (Low noise Unit)
Recovery heat exchanger specifications
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Acoustic Version: AX (Extra low noise Unit)
Recovery heat exchanger specifications
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 1.3 1.3 1.3 1.3 1.3 1.3 l
Unit specication
Cooling capacity VD(1) 365 389 457 514 581 650 kW
Power input compressor VD (1) 102 110 128 147 163 186 kW
Total power input VD (1) 117 125 146 165 184 207 kW
EER VD (1) 3.12 3.11 3.13 3.12 3.16 3.14 -
Water flow rate VD (1) 17.5 18.6 21.8 24.6 27.8 31.0 l/s
Water pressure drop VD (1) 56 58 62 65 63 60 kPa
Recovered heating capacity (1) 87.7 93.4 110 123 139 156 kW
Recovered water flow rate (1) 4.19 4.46 5.26 5.88 6.64 7.45 l/s
Recovered water pressure drop (1) 24 27 25 32 31 39 kPa
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3.8 3.8 3.8 3.8 3.8 3.8 l
Unit specication
Cooling capacity VD(1) 350 373 438 493 557 624 kW
Power input compressor VD (1) 110 119 137 158 176 200 kW
Total power input VD (1) 124 134 155 176 197 221 kW
EER VD (1) 2.82 2.78 2.83 2.80 2.83 2.82 -
Water flow rate VD (1) 16.7 17.8 20.9 23.6 26.6 29.8 l/s
Water pressure drop VD (1) 51 53 57 60 58 56 kPa
Recovered heating capacity (1) 87.7 93.4 110 123 139 156 kW
Recovered water flow rate (1) 4.19 4.46 5.24 5.90 6.66 7.45 l/s
Recovered water pressure drop (1) 24 27 25 32 31 39 kPa
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3.8 3.8 3.8 3.8 3.8 3.8 l
Unit specication
Cooling capacity VD(1) 343 366 430 483 546 612 kW
Power input compressor VD (1) 113 123 141 163 180 206 kW
Total power input VD (1) 128 138 159 181 202 227 kW
EER VD (1) 2.68 2.65 2.70 2.67 2.70 2.70 -
Water flow rate VD (1) 16.4 17.5 20.5 23.1 26.1 29.2 l/s
Water pressure drop VD (1) 49 51 55 58 56 53 kPa
Recovered heating capacity (1) 87.7 93.4 110 123 139 156 kW
Recovered water flow rate (1) 4.19 4.46 5.26 5.88 6.64 7.45 l/s
Recovered water pressure drop (1) 24 27 25 32 31 39 kPa
