Performances in heating mode - Standard Unit AB
Tw= Outlet water temperature °C kWt = Heating capacity (kW). kWa = Compressor power input (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the plate-type heat exchanger, outdoor air with 87% relative
humidity and to operation of the unit with all the fans to top speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above
sea level (Pb = 1013mbar).
The performances are declared no considering any correction due to water flow rate and water side pressure drop (gross performance).
NOTE
For air temperatures of less than 7°C, the heating capacity is declared without considering the effect of the defrosting, strictly correlated with the humidity in the outdoor air.
MOD.
TW
OUTDOOR AIR TEMPERATURE (°C D.B.)
-6 -2 2 6 9 12 15
kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa
350.5
30 283 75.5 324 75.9 354 77.0 377 77.4 404 78.3 432 79.2 462 80.1
35 281 83.6 322 84.1 352 85.3 375 85.8 402 86.8 430 87.8 460 88.8
40 279 93.0 320 93.5 350 94.8 373 95.4 400 96.5 427 97.6 457 98.7
45 278 103 318 104 348 105 370 106 397 107 424 108 454 110
50 276 115 316 116 345 117 367 118 394 119 421 121 451 122
390.6
30 300 81.2 344 81.6 376 82.8 400 83.2 429 84.2 459 85.2 491 86.1
35 299 89.9 342 90.5 374 91.7 398 92.3 427 93.3 456 94.4 488 95.5
40 297 100 340 101 372 102 396 103 424 104 454 105 485 106
45 295 111 338 112 370 113 393 114 421 115 451 117 482 118
50 293 124 336 124 367 126 390 127 419 128 448 130 479 131
440.6
30 348 92.6 399 93.1 436 94.4 464 94.9 498 96.0 532 97.1 569 98.2
35 346 103 397 103 434 105 462 105 495 106 530 108 566 109
40 344 114 395 115 432 116 459 117 492 118 527 120 563 121
45 342 127 392 127 429 129 456 130 489 132 523 133 559 135
50 340 141 389 142 426 144 453 145 486 146 519 148 555 150
490.6
30 394 108 452 108 494 110 525 110 563 112 602 113 644 114
35 392 119 449 120 491 121 523 122 560 124 599 125 641 126
40 390 132 447 133 489 135 520 136 557 137 596 139 637 141
45 387 147 444 148 485 150 516 151 553 153 592 154 633 156
50 384 164 441 165 482 167 512 168 550 170 588 172 629 174
560.6
30 440 118 504 119 551 121 586 121 629 123 672 124 719 125
35 438 131 502 132 549 134 583 134 626 136 669 137 716 139
40 435 146 499 146 545 149 580 149 622 151 665 153 711 155
45 432 162 495 163 542 165 576 166 618 168 660 170 707 172
50 429 180 492 181 538 183 572 185 613 187
656 189 702 191
630.6
30 502 139 576 140 630 142 670 142 718 144 768 146 822 147
35 500 154 573 155 627 157 666 158 715 160 764 161 817 163
40 497 171 570 172 623 174 663 175 711 177 760 180 813 182
45 494 190 566 191 619 194 658 195 706 197 755 200 807 202
50 490 211 562 213 614 216 653 217 701 219 749 222 802 224
