GENERAL SPECIFICATIONS - VERSION WITH DESUPERHEATER (VD)
IP HEAT PUMP UNIT
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Acoustic Version: AB (Standard Unit)
Recovery heat exchanger specifications
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO UNITS
OPERATING IN THE COOLING MODE.
(1): Dati riferiti a: Temperatura acqua: ingresso evaporatore :12°C - uscita evaporatore: 7°C, Temperatura aria esterna 35°C.
Dati riferiti a: Temperatura acqua: ingresso recupero:40°C - uscita recupero: 45°C.
Acoustic Version: AS (Low noise Unit)
Recovery heat exchanger specifications
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO UNITS
OPERATING IN THE COOLING MODE.
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Acoustic Version: AX (Extra low noise Unit)
Recovery heat exchanger specifications
NOTE : THE HEATING CAPACITY RECOVERED BY THE DESUPERHEATER EXCLUSIVELY REFERS TO UNITS
OPERATING IN THE COOLING MODE.
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 1.3 1.3 1.3 1.3 1.3 1.3 l
Unit specication
Cooling capacity VD(1) 355 379 443 499 562 632 kW
Power input compressor VD (1) 101 109 126 145 161 183 kW
Total power input VD (1) 115 123 144 163 183 205 kW
EER VD (1) 3.09 3.08 3.08 3.06 3.07 3.08 -
Water flow rate VD (1) 16.9 18.1 21.2 23.9 26.8 30.2 l/s
Water pressure drop VD (1) 52 55 58 62 59 57 kPa
Recovered heating capacity (1) 85.2 90.7 106 120 135 152 kW
Recovered water flow rate (1) 4.07 4.33 5.06 5.73 6.45 7.26 l/s
Recovered water pressure drop (1) 23 26 24 30 29 36 kPa
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3.8 3.8 3.8 3.8 3.8 3.8 l
Unit specication
Cooling capacity VD(1) 340 363 425 479 539 607 kW
Power input compressor VD (1) 109 117 136 156 174 198 kW
Total power input VD (1) 123 132 154 174 195 219 kW
EER VD (1) 2.76 2.75 2.76 2.75 2.76 2.77 -
Water flow rate VD (1) 16.2 17.3 20.3 22.9 25.7 29.0 l/s
Water pressure drop VD (1) 48 50 54 57 54 53 kPa
Recovered heating capacity (1) 85.2 90.7 107 120 135 152 kW
Recovered water flow rate (1) 4.07 4.33 5.09 5.72 6.45 7.25 l/s
Recovered water pressure drop (1) 23 26 24 30 29 36 kPa
MODEL 350.5 390.6 440.6 490.6 560.6 630.6 UM
Type of recovery exchanger Brazed plates -
Quantity 1 N°
Max. operating pressure on wet side 600 kPa
Total water content of recovery exchangers 3.8 3.8 3.8 3.8 3.8 3.8 l
Unit specication
Cooling capacity VD(1) 334 356 416 469 528 595 kW
Power input compressor VD (1) 112 120 140 160 178 204 kW
Total power input VD (1) 126 135 158 178 200 225 kW
EER VD (1) 2.65 2.64 2.63 2.63 2.64 2.64 -
Water flow rate VD (1) 16.0 17.0 19.9 22.4 25.2 28.4 l/s
Water pressure drop VD (1) 47 48 51 54 52 51 kPa
Recovered heating capacity (1) 85.2 90.7 106 120 135 152 kW
Recovered water flow rate (1) 4.07 4.33 5.06 5.73 6.45 7.26 l/s
Recovered water pressure drop (1) 23 26 24 30 29 36 kPa
