Performances Version with Desuperheater (VD)
GENERAL SPECIFICATIONS - VERSION WITH DESUPERHEATER (VD)
IP HEAT PUMP UNIT
Twr= Recovery outlet water temperature °C - Evaporator outlet water temperature = 7°C.
The standard performances refer to a 5°C temperature difference between the water entering and leaving the heat exchanger and to operation of the unit with all fans at
nominal or maximum speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
The performances are declared no considering any correction due to water flow rate and water side pressure drop (gross performance).
MOD.
TWR
OUTDOOR AIR TEMPERATURE (°C D.B.)
25 30 35 40 45
kWtr = Recovered HEATING CAPACITY [kW]
350.5
30
71.5 81.3 92.6 105 119
35
71.0 80.8 92.0 104 118
40
69.1 78.6 89.6 102 115
45
65.7 74.8 85.2 96.7 110
50
60.9 69.3 78.9 89.6 101
55
54.5 62.0 70.7 80.2 90.9
60
46.7 53.1 60.5 68.7 77.8
65
37.4 42.6 48.5 55.0 62.3
70
26.6 30.3 34.5 39.2 44.4
390.6
30
76.7 87.0 98.8 112 127
35
76.3 86.6 98.3 111 126
40
74.2 84.2 95.6 108 123
45
70.5 79.9 90.7 103 116
50
65.0 73.7 83.7 94.9 107
55
57.9 65.6 74.5 84.5 95.6
60
49.1 55.6 63.2 71.6 81.0
65
38.6 43.8 49.7 56.3 63.7
70
26.4 30.0 34.0 38.6 43.6
440.6
30
88.9 101 115 131 148
35
88.4 101 115 130 147
40
86.0 97.8 111 127 143
45
81.8 93.0 106 120 136
50
75.8 86.2 98.2 111 126
55
67.9 77.2 87.9 99.8 113
60
58.1 66.1 75.3 85.5 96.8
65
46.6 53.0 60.3 68.5 77.5
70
33.1 37.7 42.9 48.7 55.2
490.6
30
102 115 131 148 168
35
101 115 130 147 167
40
98.2 111 126 143 162
45
93.2 106 120 136 154
50
86.0 97.5 111 126 142
55
76.6 86.8 98.6 112 126
60
64.9 73.6 83.6 94.8 107
65
51.0 57.9 65.7 74.5 84.3
70
35.0 39.6 45.0 51.0 57.7
560.6
30
116 132 150 170 192
35
113 129 146 165 187
40
111 125 142 161 182
45
105 119 135 153 173
50
96.4 109 124 141 159
55
85.0 96.2 109 124 140
60
70.7 80.1 91.0 103 117
65
53.6 60.7 69.0 78.2 88.4
70
33.6 38.1 43.3 49.1 55.5
630.6
30
130 148 168 190 214
35
127 144 164 186 209
40
124 141 160 181 204
45
118 134 152 172 194
50
108 123 140 158 178
55
95.1 108 123 139 157
60
78.8 89.5 102 115 130
65
59.1 67.2 76.4 86.4 97.5
70
36.2 41.1 46.7 52.9 59.7
