Ferroli RHA series User Manual

55
NOTES:
Values valid for IP and IR units, STANDARD, LOW NOISE and EXTRA LOW NOISE unit, WITH or WITHOUT hydronic kit.
FLA= Full load current at maximum tolerated conditions
LRA= Locked rotor current
FLI= Full load power input at maximum tolerated conditions
MIC= Maximum instantaneous current of the unit
Values relative to a 400V~3~50Hz power supply voltage rating
ELECTRICAL CONNECTIONS
Specications of pumping module accessory MP AM STD and MP SS STD
Specications of pumping module accessory High working head MP AM HP1 and MP SS HP1
Summary tables (total values):
Specications of pumping module accessory MP PS STD
Units without pumping module
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Total maximum load current [ FLA ] 287 302 355 399 451 494 A
Total maximum power input [ FLI ] 171 182 211 237 272 304 kW
Total maximum starting current [ MIC ]
538 529 605 649 771 815 A
Units with pumping module MP PS STD (1 or 2 pumps)
Total maximum load current [ FLA ] 299 314 376 420 472 515 A
Total maximum power input [ FLI ] 178 189 224 250 285 317 kW
Total maximum starting current [ MIC ]
550 541 626 670 792 835 A
Units with pumping module MP AM STD and MP SS STD (1 or 2 pumps)
Total maximum load current [ FLA ] 301 316 376 420 472 515 A
Total maximum power input [ FLI ] 179 190 224 250 285 317 kW
Total maximum starting current [ MIC ]
552 543 626 670 792 835 A
Units with pumping module MP AM HP1 and MP SS HP1 (1 or 2 pumps)
Total maximum load current [ FLA ] 308 323 382 426 478 521 A
Total maximum power input [ FLI ] 184 195 227 253 288 320 kW
Total maximum starting current [ MIC ]
558 550 632 676 798 842 A
Summary Fan specifications
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Power supply
400 - 3 - 50 V-ph-Hz
FLA AB
34.4 43.0 51.6
A
LRA AB
120 150 180
A
FLI AB
16.0 20.0 24.0
kW
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Power supply
400 - 3 - 50 V-ph-Hz
FLA AB
12.0 12.0 20.8 20.8 20.8 20.8
A
LRA AB
96.0 96.0 166.4 166.4 166.4 166.4
A
FLI AB
7.0 7.0 13.0 13.0 13.0 13.0
kW
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Power supply
400 - 3 - 50 V-ph-Hz
FLA AB
14.0 14.0 20.8 20.8 20.8 20.8
A
LRA AB
112.0 112.0 166.4 166.4 166.4 166.4
A
FLI AB
8.2 8.2 13.0 13.0 13.0 13.0
kW
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Power supply
400 - 3 - 50 V-ph-Hz
FLA AB
20.8 20.8 20.8 20.8 20.8 27.0
A
LRA AB
166.4 166.4 166.4 166.4 166.4 216
A
FLI AB
13.0 13.0 13.0 13.0 13.0 16.0
kW
Single Fan specifications
UNIT
350.5 390.6 440.6 490.6 560.6 630.6
UM
Power supply
400 - 3 - 50 V-ph-Hz
FLA AB
4.3
A
LRA AB
15.0
A
FLI AB
2.0
kW
