A Technical appendix
Festo – GDCP-CMMS-AS-G2-S1-EN – 1306NH – English 39
Auxiliarysupply24V,0V–output[X3.1,X3.3]
Feature Logic supply voltage routed out of the motor controller (fed
in at [X9], not additionally filtered or stabilised).
Nominal voltage [V] 24
Nominal current [mA] 100 (not short-circuit proof)
Voltage drop [V] ≤ 1 (at nominal current)
Tab. A.8 Technical data: electrical data of the auxiliary supply output [X3]
Cabling [X3]
Max. cable length [m] 30
Screening When wiring outside the control cabinet, use screened
cable. Guide screening into the control c abinet / attach to
thesideofthecontrolcabinet.
Cable cross section (flexible conductors, wire end sleeve with insulating collar)
One conductor [mm²] 0.25 … 0.5
Two conductors [mm²] 2 x 0.25 (with twin wire end sleeves)
Tightening torque M2 [Nm] 0.22 … 0.25
Tab. A.9 Technical data: c abling at [X3]
