Festo Controller CECC
8
Removal
Note
• Never remove the CECC from the H-rail while it is still wired.
• Make sure that all cable connections are disconnected before removing the CECC.
Figure: Removal from an H-rail
Removal instructions:
1. Pull the mounting clip 2 on the CECC in the direction of the arrow using a suitable tool
(e.g. screwdriver). This releases the device.
2. Tilt the released device away from the H-rail.
3. Remove the device from the H-rail via the mounting clip 1.
