Festo Controller CECC User Manual

Festo Controller CECC
4
2 System overview
2.1 Controller CECC
Variant Features Codesys target system ID
1)
CECC-D – CANopen interface
– 14 inputs/8 outputs
16#103D9C43
CECC-LK As for CECC-D plus:
– 4 IO-Link master interfaces
– 1 IO-Link device interface
16#103D9C41
CECC-S As for CECC-D plus:
– 2 RS232 interfaces
– 1 multiple communication interface, either
encoder, RS485 or RS422
– 1 IO-Link master interface
– 1 IO-Link device interface
16#103D9C42
1) Device type code for use in the communication settings ( section "Adding a device").
Table: Variants of the CECC
All variants offer...
– Programming using CODESYS V3 provided by Festo (pbF) in accordance with IEC 61131-3
– Programming, communication and visualisation via Ethernet
– Communication via CANopen
– Controller configuration using CODESYS V3 pbF for commissioning, programming and diagnosing the
system
– Process visualisation within CODESYS V3 pbF using a display and operator unit CDPX and the
Software Designer Studio (available separately), use of the OPC server for connecting to an OPC
client or use of the web visualisation under Codesys
• Use the CODESYS V3 pbF software package to configure the device.
The current version of the software package can be found in the download area under
www.festo.com/download.
2.2 Festo Service
The following information and data is required for speedy handling of a support inquiry by Festo Service:
– Response to the command "getdevinfo" ( PLC shell)
– CECC project ( menu command in Codesys: File - Project Archive - Save/Send Archive)
– Version of the programming environment ( menu command in Codesys: Help - Information - Display
detailed version Information)
– Controller data  Export of the device properties of the FFT

Festo Controller CECC Specifications

General

Brand	Festo
Model	Controller CECC
Category	Controller
Language	English
