Input modules can be connected to one of the follow-
ing:
– the CP connection of a valve terminal
– the CP connection of an output module
– directly to the CP connection of the node.
Maximum one input module can be connected to each
line. The address range that a module occupies is
determined by the line to which it is connected when
the operating voltage is switched on.
1. Input module type CP-E16...-M...
1-20 CP-E16...-M... 9611A
