1.3.1 Connecting sensors
Use the following cable and plugs for connecting the
sensors.
Type Plug Cable
CP-E16-M12x2 PG7 KM12-DUO-...
CP-E16-M8 Use the plug with
union nut with
thread M8x1.
KM8-M8-GSGD-...
Fasten the plugs with the aid of the union nuts in order
to avoid unintentional loosening e.g. due to vibration.
Seal the unused sensor connections with the protective
caps supplied. Only then is compliance with class of
protection IP65 ensured.
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-9
