1.5 Technical specifications CP-E16...-M...
Technical specifications Type CP-E16-M... (PNP) Type CP-E16N-M... (NPN)
Temperature range:
- operation
- storage/transport
-5
o
C ... + 50
o
C
-20
o
C ... + 70
o
C
Relative humidity 95% non condensing
Protection class as per EN
60 529
Plug connector inserted or
fitted with
protective cap
IP 65
Chemical resistance See Festo pneumatic catalogue (resistance table)
Electromagnetic compatibility
- interference emission
- resistance to interference
Tested as per EN 55011 limit value class A
Tested as per EN 50082-2
Digital inputs
- Design
16 inputs
as per IEC 1131-2 type
2 inputs 24 V DC
(positive switching)
16 inputs
as per IEC 1131-2 type
2 inputs 24 V DC
(negative switching)
- Logic level:
ON
OFF
> 11 V
< 5 V
> V
D
-11 V
< V
D
- 5 V
- Current consumption
(at 24 V)
(input current from sensor
to input)
at "logic 1"
typ. 8 mA
at "logic 0"
typ. 8 mA
- Response delay (at 24 V) typ. 5 ms typ. 5 ms
Sensor supply max. 0.5 A
(electronic short circuit protection)
Electrical isolation None
Internal current consumption
of electronic components
< 40 mA max. 90 mA
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-25
