2.5 Technical specifications
Technical specifications Type CP-A08-M12
(PNP outputs)
Type CP-A08N-M12
(NPN outputs)
Temperature range:
- operation
- storage/transport
-5
o
C ... + 50
o
C
-20
o
C ... + 70
o
C
Relative humidity 95% non condensing
Protection class as per EN 60 529
Plug connector inserted or fitted with
protective cap
IP 65
Chemical resistance See Festo pneumatics catalogue (resistance table)
Electromagnetic compatibility
- interference emission
- resistance to interference
Tested as per EN 55011 limit value class A
Tested as per EN 50082-2
Load voltage connection
- rated value
(protected against incorrect polarity)
- tolerance
- residual ripple
- Isolation resistance
- internal current consumption of
electronic components
Electrically isolated load voltage via additional
M18 plug connector.
24 V
± 25%
4 Vpp (within tolerance)
500 V
< 40 mA
Digital outputs
-design
- loading per digital output
8 outputs
as per IEC 1131-2;
24 V DC
positive switching
0.5 A
8 outputs
as per IEC 1131-2;
24 V DC
negative switching
0.5 A
- Electronic fuse
(short circuit, overload)
trigger current
response time
min. 750 mA
max. 1.5 ms
typ. 1 A
max. 1.5 ms
2. Output module type CP-A08...-M12
CP-A08...-M12 9611A 2-17
