The diagram below shows the pin assignment of the
load voltage connection on the output module.
Pin
assignment
n.c. = not connected
Fig. 2/9: Pin assignment of load voltage connection
DIAG
POWER
OUTPUT-P
Pin 1:
n.c.
Pin 4:
PE
Pin 3:
0 V
Pin 2:
24 V DC ± 25%
2. Output module type CP-A08...-M12
2-14 CP-A08...-M12 9611A
