1) Selective mode change – vendor ID
With the “switch mode selective – vendor ID” command, only
the mode of the LSS slave with the specified vendor ID is
changed.
COB-ID
Command
0x7E5 Byte 0 1 2 3 4 5 6 7
Data 0x40 VendorID 0x00 0x00 0x00 0x00 0x00 0x00
Tab. 2/4: Switch mode selective – vendor ID
The “switch mode selective – vendor ID” command is not confirmed by the LSS slave.
2) Selective mode change – product code
With the “switch mode selective – product code” command,
only the mode of the LSS slave with the specified product
code is changed.
COB-ID
Command
0x7E5 Byte 0 1 2 3 4 5 6 7
Data 0x41 ProdCode 0x00 0x00 0x00 0x00 0x00 0x00
Tab. 2/5: Switch mode selective – product code
The “switch mode selective – product code” command is not confirmed by the LSS slave.
