1. Installation
1-30
Festo P.BE-FB14-EN en 1411d English
1.3.6 Further connection possibilities for the fieldbus with adapters
Caution
When connecting the fieldbus interface and the power
supply for the bus interface, pay attention to the
polarity.
Connect the screening.
There are further connection options for the CPX terminal
with adapters which can be ordered separately from Festo:
– M12 adapter 5-pin (protection class IP 65)
type FBA-2-M12-5POL
– Screw terminal adapter 5-pin (protection class IP20)
type FBA-1-SL-5POL
