2. Commissioning
2-15
Festo P.BE-FB14-EN en 1411d English
Save the configuration
With the “store configuration” command, the new node ID
and the new baud rate are stored.
This command is only possible in the configuration mode.
COB-ID
Command
0x7E5 Byte 0 1 2 3 4 5 6 7
Data 0x17 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Tab. 2/14: Store configuration
COB-ID
Acknowledge
0x7E4 Byte 0 1 2 3 4 5 6 7
Data 0x17 Error code Error ex
tension
0x00 0x00 0x00 0x00 0x00
Tab. 2/15: Answer to store configuration
Error code:
– 0 Successful saving of the settings
– 1 Saving is not supported by the LSS slave.
– 2 No access to the storage medium.
– 0xFF Not all switch elements 1 … 7 of the DIP switch 3 are at OFF. The bus node
is not in the LSS mode.
Error extension:
– Reserved
