2. Commissioning
2-28
Festo P.BE-FB14-EN en 1411d English
Remote controller operating mode
In the remote controller operating mode (DIL switch 1) only
the PDOs 1 are assigned. They contain 64 logical I/Os for
data exchange with the remote controller.
Receive PDO 1
Transmit PDO 1
Receive PDO 2 … 4
Transmit PDO 2 … 4 Unused
Unused
O0…O7
I0…I7 I56…I63I8…I15 I16…I23 I24…I31 I32…I39 I40…I47 I48…I55
O8…O15
O16…O23
O24…O31
O32…O39
O40…O47 O48…O55 O56…O63
Fig. 2/2: 64 logical I/Os in the PDO 1 in the remote controller operating mode
