Brewer Setup
NOTE-Assemble legs after unpacking the brewer and before connection to utilities
1) attach legs for 3 Liter/ 1 Gallon dispensing
STANDARD WITH UNIT
1” legs -
Attach this length for
3 Liter air pot configuration
NOT INCLUDED. Purchase separately
2-1/2” legs -
Attach this length for
1 Gallon dispenser or 3 liter air pot.
Part number 1073.00016.00
3 required for CBS-1232
4 required for CBS-1231
Legs are sent from factory inside brew basket. Attach legs before installing
2) Adjust dispenser locator for either 3 Liter / 1 Gallon dispensing
Set Dispenser Locator
 Shown with 1 gallon dispenser
locator
-(User option)
Shown with 3 liter air pot Locator

-(Factory installed)
Layout of the brewer
Operation and service
For installing brewer
Brew basket
Keypad for brewer operation
Hot Water Faucet
ON/OFF Switch
Air pot or Dispenser Locator
(Two for twin side)
SELECT brewer model
From SERVICE MENU (Page 9) go to position F3
Select model and SAVE and EXIT (Page 11)
Be certain to SAVE new settings
USB
Connection
Power
Switch
Electrical
Connection
Water
Supply
Connection
