FIBARO ROLLER SHUTTER 3 User Manual

23
ZWAVE SPECIFICATION
Protection CC:
Protection Command Class allows to prevent local or remote control of
the device.
Type of protection State Description
Local 0
Unprotected - The device is not pro-
tected, and may be operated normally
via S1 or S2
Local 2
No operation possible – S1 and S2
cannot change relay state, any other
functionality is available (menu)
RF (remote) 0
Unprotected - The device accepts and
respond to all RF Commands
RF (remote) 1
No RF control – command class Basic
and Switch Binary are rejected, every
other command class will be handled
Meter Command Class:
Same for Root, Endpoint 1 and Endpoint 2.
Meter Type Scale Rate Type Precision Size
Electric
[0x01]
Electric_kWh
[0x00]
Import
[0x01]
2 4
Electric
[0x01]
Electric_W
[0x02]
Import
[0x01]
1 2

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
