FIBARO ROLLER SHUTTER 3 User Manual

29
ADVANCED PARAMETERS
150. Force calibration
By setting this parameter to 2 the device enters the calibration mode.
The parameter relevant only if the device is set to work in positioning
mode (parameter 151 set to 1, 2 or 4).
Available settings: 0 - device is not calibrated
1 - device is calibrated
2 - force device calibration
Default setting: 0 Parameter size: 1 [byte]
151. Operating mode
This parameter allows adjusting operation according to the connect-
ed device.
Available settings: 1 – roller blind (with positioning)
2 – Venetian blind (with positioning)
3 – gate (without positioning)
4 – gate (with positioning)
5 – roller blind with built-in driver
6 – roller blind with built-in driver (impulse)
Default setting: 1 Parameter size: 1 [byte]
152. Venetian blind - time of full turn of the slats
For Venetian blinds (parameter 151 set to 2) the parameter deter-
mines time of full turn cycle of the slats.
For gates (parameter 151 set to 3 or 4) the parameter determines time
after which open gate will start closing automatically (if set to 0, gate
will not close).
The parameter is irrelevant for other modes.
Available settings: 0-90000 (0 - 900s, every 0.01s) - time of turn
Default setting: 150 (1.5s) Parameter size: 4 [bytes]
ROLLER SHUTTER OPERATION CONFIGURATION

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
