3 Web Configuration Guide
d) Click OK to save the configurations.
2. Enter http://192.168.1.1 (default management IP address of the ONT) in the
browser address bar of the computer, and press the Enter key to bring up the
user login dialog box.
3. Enter the administrator username and password in the login dialog box. Access
the Web GUI after the password is authenticated.
Caution:
The system will log out automatically if no user operation is detected in
five minutes.
Layout of the Web Configuration GUI
The Web configuration GUI comprises three parts, as shown in Figure 3-1.
u Navigation bar. Click the link to access the corresponding configuration
management page.
u Link bar. Click the link to access the sub-page for corresponding configuration
management.
u Configuration management area. Displays the items selected in the navigation
bar and link bar.
(1) Navigation bar (2) Link bar (3) Configuration
management area
Figure 3-1 Web Configuration GUI
Version: A
23
